SD 1200.1 EVO 5 - 1Ω
Power @ 4Ω: 1 X 522 WRMS
Power @ 2Ω: 1 X 792 WRMS
Power @ 1Ω: 1 X 1200 WRMS -
SD 1200.1 EVO 5 - 2Ω
Power @ 4Ω: 1 X 796 WRMS
Power @ 2Ω: 1 X 1200 WRMS
Power @ 1Ω: 1 X N/A -
Frequency Response (-3dB): 5Hz ~ 25kHz
-
Subsonic Filter: 5Hz ~ 80Hz
-
Low Pass Filter: 50Hz ~ 1kHz
-
Bass Boost: 0dB ~ 12dB @ 50Hz
-
Operating Voltage: 9V ~ 16V
-
Signal-Noise Ratio: 95dB
-
Input Sensitivity: 0.2V ~ 2V
-
Current Draw (Music):
1Ω: 54A
2Ω: 52A -
Current Draw (Max):
1Ω: 108A
2Ω: 105A -
Total Efficiency:
1Ω: 88%
2Ω: 91% -
Damping Factor: >2000
-
Power Cable: 16mm² (5 AWG)
-
Audio Output Cable:
1Ω: 2 x 4 mm² (6 AWG)
2Ω: 2 x 2,5 mm² (13 AWG) -
Recommended Fuse (Music): 70A
-
Recommended Battery: 70Ah
-
Width: 13.6 cm / 5.4 in
-
Length: 18 cm / 7.1 in
-
Height: 5.48 cm / 2.1 in
-
Weight: 1.12 Kg
