SD 1200.4 EVO 5 - 2Ω
Power @ 1Ω: 4 X 300 WRMS
Power @ 2Ω: 4 X 198 WRMS
Power @ 4Ω: 4 X 130 WRMS
Bridge Power @ 2Ω: 2 X 600 WRMS
Bridge Power @ 4Ω: 2 X 396 WRMS -
SD 1200.4 EVO 5 - 4Ω
Power @ 1Ω: N/A
Power @ 2Ω: 4 X 300 WRMS
Power @ 4Ω: 4 X 198 WRMS
Bridge Power @ 2Ω: N/A
Bridge Power @ 4Ω: 2 X 600W RMS -
Frequency Response (-3dB): 5Hz ~ 22kHz
-
Low Pass Filter (12dB/oct): 80Hz
-
High Pass Filter (12dB/oct): 80Hz
-
Operating Voltage: 10V ~ 16V
-
SNR: 87dB
-
Input Sensitivity (RCA): 0.2V ~ 2V
-
Current Draw (music): 59A
-
Current Draw (max.): 118A
-
Total Efficiency: 81%
-
Damping Factor: 200
-
Power Cable: 16mm² (5 AWG)
-
Speaker Cable: 2 x 2mm² (14 AWG)
-
Recommended Fuse (music): 60A
-
Recommended Battery (minimum): 60Ah
-
Width: 6.7" / 12.1 cm
-
Length: 5.4" / 17 cm
-
Height: 2.2" / 5.48 cm
-
Weight: 2.36 lb / 1,07 kg
