Klik hier voor de SD 12000.1 EVOX (hogere kwaliteit mosfets, grotere power supply section, tiffany rca, efficiënter en robuuster in alle aspecten vergleken met de EVO 5 componenten)
Klik hier voor de handleiding - Download hier de 1kHz test tone
-
SD 12000.1 EVO 4.0 - 1Ω
Power @ 1Ω: 1 X 12000W RMS
Power @ 2Ω: 1 X 7920W RMS
Power @ 4Ω: 1 X 5227W RMS -
SD 12000.1 EVO 4.0 - 2Ω
Power @ 1Ω: N/A
Power @ 2Ω: 1 X 12000W RMS
Power @ 4Ω: 1 X 7920W RMS -
Operating Voltage: 8V – 16V
-
Current Draw (Music): 643A
-
Current Draw (Max): 1287A
-
Recommended Fuse (Music): 2 X 350A
-
Total Efficiency: 74%
-
Damping Factor: 200
-
Frequency Response: 5Hz – 6kHz
-
SNR: 71dB
-
Crossover
LP: 50Hz – 6kHz
HP: 5Hz – 80Hz 12dB/8ª -
Width: 8.8 in / 22,5 cm
-
Length: 20.8 in / 53 cm
-
Height: 2.8 in / 7,1 cm
-
Weight: 7 Kg
